BEG-561-440-130 Bridge-Half-Wave Rectifier 6-pole 1300 ms

The bridge-half-wave rectifiers conduce to supply electromagnetic spring-applied DC brakes which are released for operation with such rectifers.

Example: 205 VDC coil on 230 VAC mains

The rectifiers are protected against overvoltage by input and output varistors.

Technical data:

Manufacturer: Bridge / half-wave rectifier

Type: BEG-561-440-130

Connection: 6-polig

Max. mains voltage: 270V~

Max. supply voltage: 440 V AC

Max. DC current: 3,0 A / 1,5 A 60°C

Mounting position: horizontal

Over-excitation time: 1300 ms
